Our Trailers

With more standard features and higher quality components than our competitors, we are confident that you will be surprised by IMAGO. Our trailers exemplify craftsmanship and professionalism. In addition to being aesthetically pleasing, our products have the quality and strength to back it up. Form and Function. Quality begins with Precision. Don't take our word for it. Visit our competitors, then visit us. The choice will be clear.


Dump Trailer Comparison

SuperMax
SSR
Standard

GVWR

14,000 lbs 10,400 lbs 10,400 lbs

Payload Capacity

9,900 lbs 6,900 lbs 7,200 lbs

Dumping Capacity

14,000 lbs 7,500 lbs 7,500 lbs

Wheel Size

16" 15" 15"

Tire Size

235/80/R16 225/75/D15 225/75/D15

Tire Rating

E D D

Axles

(2) @ 7,000 lb each (2) @ 5,200 lb each (2) @ 5,200 lb each

Brakes

4 Wheel 12" Electric Drum 4 Wheel 12" Electric Drum 4 Wheel 12" Electric Drum

Hydraulic Power Unit

Single Acting Single Acting Single Acting

Hydraulic Hoist

Rugby Scissor Hoist Cylinder Cylinder

Operating Pressure

3,400 psi 3,400 psi 3,400 psi

Frame

R/T Frame R/T Frame R/T Frame

Fenders

HD Tough Terrain MD Tough Terrain MD Tough Terrain

Ramps

(2) Rear Sliding 6' (2) Rear Sliding 6' N/A

Ramp Mounts

Solid Bar Solid Bar N/A

Tail Lights

(4) LED Oval (4) Incandescent Oval (4) Incandescent Oval

Backup Lights

(2) Incandescent Oval N/A (option) N/A (option)

Tail Light Enclosure

IPC 3 Pod IPC 2 Pod IPC 2 Pod

Storage Box

IPC IPC IPC

Tongue Jack

7,000 lb Drop Leg 7,000 lb Drop Leg 7,000 lb Drop Leg

Coupler

2 5/16 14,000lb (Adjustable) 2 5/16 10,000lb (non-Adjustable) 2 5/16 10,000lb (non-Adjustable)
